Specifications
Format
- Lens Construction
-
8 Elements in 6 Groups
- Focal Length
-
30mm
- 35mm Equivalent Focal Length
-
Approx. 45mm
- Lens F number
-
F2.8~F16
- Number of Diaphragm Blades
-
9 Blades
- Shooting Range
-
28cm～∞、1m～∞ (LIMIT mode)
- Maximum Magnification Shooting
-
1：7.6
Image Sensor
- Image Sensor
-
FOVEON X3® Direct Image Sensor (CMOS)
- Image Sensor Size
-
23.5×15.7mm
- Pixels
-
Total Pixels: 48MP
Effective Pixels: 46MP (4,800×3,200×3)
- Aspect Ratio
-
3:2
Recording System
- Storage Media
-
SD Card, SDHC Card, SDXC Card, Multi Media Card
- Recording Mode
-
Lossless compression RAW data (12-bit, High, Medium, Low), JPEG (High, Medium, Low), RAW+JPE, Movie (AVI), VGA : 640×480 (Image area 640×426)
- Color Mode
-
8 types ( Standard, Vivid, Neutral, Portrait, Landscape, B&W, Sepia, FOV Classic Blue )
- Capture File Size
-
RAW
High Approx. 45 MB (4,704×3,136×3)
Medium Approx. 24 MB (3,264×2,176×3)
Low Approx. 12 MB (2,336×1,568×3)JPEG High
Fine Approx. 10 MB (4,704×3,136)
Normal Approx. 5.6 MB (4,704×3,136)
Basic Approx. 4.2 MB (4,704×3,136)JPEG Medium
Fine Approx. 5.0 MB (3,264×2,176)
Normal Approx. 2.7 MB (3,264×2,176)
Basic Approx. 2.0 MB (3,264×2,176)JPEG Low
Fine Approx. 2.5 MB (2,336×1,568)
Normal Approx. 1.4 MB (2,336×1,568)
Basic Approx. 1.0 MB (2,336×1,568)
White Balance
- Settings
-
8 types ( Auto, Daylight , Shade, Overcast, Incandescent, Fluorescent, Flash, Custom )
Autofocus
- Auto Focus Type
-
Contrast Detection Type
- AF Point
-
9 points select mode, Free move mode (It is possible to change the size of Focus Frame to Spot, Regular and Large.)
- Focus Lock
-
Shutter release halfway-down position (AF lock can be done by AE lock button from menu setting)
- Manual Focus
-
Focus Ring Type
Exposure Control
- Metering Systems
-
Evaluative Metering, Center-Weighted Average Metering, Spot Metering
- Exposure Control System
-
(P) Program AE (Program Shift is possible), (S) Shutter Speed Priority AE, (A) Aperture Priority AE, (M) Manual
- ISO Sensitivity
-
AUTO (ISO200～ISO800) ISO100, 200, 400, 800, 1600, 3200, 6400
- Exposure Compensation
-
±3EV (1/3 stop increments)
- AE Lock
-
AE lock button
- Auto Bracketing
-
Appropriate, under, over; 1/3EV steps up to ±3EV for appropriate exposure
Shutter
- Shutter Speed
-
1/2000* – 30sec. (*Depending on the aperture value, shutter speed changes)
- Drive Modes
-
Single, Continuous, Self Timer (2sec. /10sec.), Interval timer, Unlimited Shooting
LCD Monitor
- Type
-
TFT color LCD monitor
- Monitor Size
-
3.0 inches
- LCD Pixels
-
Approx. 920,000
Menu
- LCD Monitor Language
-
English / Japanese / German / French / Spanish / Italian / Chinese (Simplified) / Korean / Russian / Chinese(Traditional) / Nederlands / Polski / Português / Dansk / Svenska / Norsk / Suomi
Interfaces
- Interfaces
-
USB (USB2.0), Video Out (NTSC/PAL), Audio Out (Monaural)
Power Source
- Power
-
Li-ion Battery BP-41, AC Adapter SAC-5 (with DC Connector CN-11) (Optional)
Dimensions and Weight
- Dimensions
-
121.5mm/4.8″ (W),66.7mm/2.6″ (H), 59.2mm/2.3″ (D)
- Weight
-
355g/12.5oz(without battery and card)
Battery life
- Battery life
-
Approx. 97 (+25°c)
Accessories
- Accessories
-
Lens Cap (on the camera), Hot Shoe Cover (on the camera), Strap, Li-ion Battery BP-41 (2 pieces), Battery Charger BC-41 (It is included only when the type of Battery charger is “Inlet” type.), USB Cable, Audio Video Cable, SIGMA Photo Pro Disc , Instruction Manual, Limited Warranty, Warranty Sticker
Product Barcode
- Product Barcode
-
DP2 Merrill : 00-85126-92912-1 (discontinued)
